142 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019

Chapter 6 Connect to Different EtherNet/IP Network Levels

Configure Linear/DLR Mode in RSLinx Classic Software

Remember, the EtherNet/IP Mode is Dual-IP by default. You must change the

mode to use Linear/DLR mode.

For more information on how to change the controller EtherNet/IP mode, see

Change the EtherNet/IP Mode on page 144.

The new mode choice is displayed on the General tab in the Controller

Properties dialog box.
