Allen-Bradley CompactLogix 5480 User Manual

248 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019
Chapter 11 Troubleshoot the Controller
Notification in the Tag Editor
General and diagnostic module faults are reported on the Monitor Tags tab of
the Logix Designer application tag editor.
The Value field indicates a fault with the number 1.
Fault Information in Controller Properties Dialog Box
You can use the following tabs on the Controller Properties dialog box to
troubleshooting the controller:
•
Major Faults
•
Minor Faults
•
Network
