Rockwell Automation Publication 5069-UM002A-EN-P - January 2019 119

EtherNet/IP Network Chapter 5

Figure 13 - Example EtherNet/IP Nodes

The Capacity tab in the Controller Properties dialog box tracks the number of

Ethernet nodes that are used in a project. This graphic is representative of the

project that is shown in

Figure 13.
