Rockwell Automation Publication 5069-UM002A-EN-P - January 2019 145

Connect to Different EtherNet/IP Network Levels Chapter 6

Change the EtherNet/IP Mode in the Logix Designer Application

To change the EtherNet/IP mode in the Logix Designer application, complete

the following steps.

1. Confirm that the project is offline.

2. Access the Controller Properties dialog box.

3. On the General tab, click Change IP Mode.

IMPORTANT This example shows the EtherNet/IP mode change from Dual-IP mode to

Linear/DLR mode. The same tasks apply to change from Linear/DLR mode to

Dual-IP mode.
