78 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019

Chapter 2 Connect to the Controller

Download Controller Firmware Files as Part of the Windows Kit

You can download controller firmware as part of the Windows kit that is also

available at the PCDC.

http://compatibility.rockwellautomation.com/Pages/home.aspx

The file not only provides you with the latest controller firmware revision but

also the Windows files necessary to install the latest Operating System installer

on your controller. The Operating System installer is used to install the COS.

For more information on how to use the Windows kit, see

page 231.
