Rockwell Automation Publication 5069-UM002A-EN-P - January 2019 87
Start to Use the Controller Chapter 3
Upload from the Controller
When you upload a project from the controller, it copies the project from the
controller to the Logix Designer application. To upload a project, use one of
the following methods:
•
Use the Who Active Dialog Box to Upload, page 87
•
Use the Controller Status Menu to Upload, page 89
Use the Who Active Dialog Box to Upload
You can use the features of the Who Active dialog box to upload from your
controller after you have set the communication path. Complete the following
steps to upload from the controller.
1. Click the Who Active icon.
2. Expand the communication path and select the controller.
3. Click Upload.
TIP In this section, an Ethernet port is the communication path. You can also use
the USB port.
