Status Indicators Appendix A
RUN Indicator
The RUN indicator shows the current mode of the controller.
To change the controller mode, you can use the mode switch on the front of the
controller or the Controller Status menu in the Logix Designer application.
FORCE Indicator
The Force indicator shows if I/O forces are enabled on the controller.
Table 36 - RUN Indicator
State Description
Off The controller is in Program or Test mode.
Steady green The controller is in Run mode.
Table 37 - FORCE Indicator
State Description
Off No tags contain I/O force values.
Solid amber I/O forces enabled. If any I/O force values exist, they are active.
IMPORTANT: Use caution if you enable I/O forces. All existing I/O force values take effect
immediately.
Flashing yellow I/O forces exist in the application, but are not active because I/O forces are not enabled.
IMPORTANT: Use caution if you enable I/O forces. All existing I/O force values take effect
immediately.
