52 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019

Chapter 2 Connect to the Controller

Connect a USB Cable

Use the USB connection to update firmware and download programs.

Figure 10 - USB Connection

ATTENTION: The USB port is intended only for temporary local

programming purposes and not intended for permanent connection. The

USB cable is not to exceed 3.0 m (9.84 ft) and must not contain hubs.

WARNING: Do not use the USB port in hazardous locations.

5069-L46ERMW

CONTROLLER

™

NET B1

LINK B1

NET A1

LINK A1

NET A1

NET A2

SPEED X1

LINK X1

RUN

FORCE

FAN 1

FAN 2

CompactLogix 5480

UPS
