Rockwell Automation Publication 5069-UM002A-EN-P - January 2019 15
CompactLogix 5480 System Chapter 1
Controller Features
Table 2 describes features available on CompactLogix 5480 controllers.
Table 2 - CompactLogix 5480 Controller Features
Feature Description
Onboard memory Logix control engine: 20 MB
Windows 10 (commercial operating system on controller):
• RAM - 6 GB
• SSD - 64 GB
Controller tasks • 32 tasks
• 1000 programs/task
• Event tasks; all event triggers
Communication ports • Three USB ports
– One device port for Logix control engine
– Two host ports for COS
• Four Ethernet ports
– Three for Logix control engine
– One for COS
For more information on the ports, see
Table 3 on page 18.
EtherNet/IP™ network topologies supported • Device Level Ring (DLR)
• Star
• Linear
EtherNet/IP nodes supported, max 250
EtherNet/IP modes • Linear/DLR mode
• Dual-IP mode
For more information on EtherNet/IP modes, see Chapter 6,
Connect
to Different EtherNet/IP Network Levels on page 127.
Integrated motion axes supported 512 - Can be any combination of physical, virtual, or consumed.
IMPORTANT: Of the physical axes, you can only configure 150 axes
for Position Loop control. Axes/ms, max is 100.
Local I/O modules, max 31
Programming languages • Ladder Diagram (LD)
• Structured Text (ST)
• Function Block Diagram (FBD)
• Sequential Function Chart (SFC)
