42 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019
Chapter 2 Connect to the Controller
Out-of-box State
The following conditions apply when the CompactLogix 5480 controller is in
the out-of-box state:
• EtherNet/IP™ mode is Dual-IP mode.
For more information on the EtherNet/IP mode options, see Chapter 6,
Connect to Different EtherNet/IP Network Levels on page 127.
• Ethernet ports are DHCP-enabled but do not have unique IP addresses
assigned to them.
If the controller is connected to a DHCP server at power-up, IP
addresses are assigned automatically. If the controller is not connected to
a DHCP server at power-up, you must assign unique IP addresses to the
ports.
To assign IP addresses, complete the steps that are described in
Set the
Controller IP Address on page 53.
• Uses firmware revision 1.xxx.
You must update the firmware revision before you can use it in a Logix
Designer application project and before you can use the COS.
For more information on how update controller the firmware revision,
see
page 69.
• Does not contain a controller project.
For more information on how to create a project, see
page 79.
• A licensed COS is pre-installed on the controller and ready for initial
set-up. However, as noted above, you cannot start the COS until a
working controller firmware revision is installed on the controller.
