Allen-Bradley CompactLogix 5480 User Manual

122 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019
Chapter 5 EtherNet/IP Network
Star Network Topology
A star network topology is a traditional EtherNet/IP network that includes
multiple devices that are connected to each other via an Ethernet switch.
Figure 16 - CompactLogix 5480 Controllers in a Star Network Topology
Integrated Architecture Tools
For more information when you design your CompactLogix 5480 system, see
the Integrated Architecture® Tools and Resources webpage. For example, you
can access the Popular Configuration Drawings with different EtherNet/IP
network topologies.
The tool and resources are available at:
http://www.rockwellautomation.com/
global/products-technologies/integrated-architecture/tools/overview.page
02
0
1734-AENTR
Module
Status
Network
Activity
Network
Status
Point Bus
Status
System
Power
Field
Power
POINT I O
Link 1
Activity/
Status
Link 2
Activity/
Status
IP ADDRESS
527
F1
F2
F3
F4
F5
F6
F7
F8
F9
F10
F11
F12
F13
F14
F15
F16
™
NET B1
LINK B1
NET A1
LINK A1
NET A2
NET A2
SPEED X1
LINK X1
OK
RUN
FORCE
FAN 1
SD
FAN 2
CompactLogix 5480
B1
A1
1
2
A2
5069-L46ERMW
CONTROLLER
UPS
MP
SA
R
B
F
CompactLogix 5480 Controller
Compact 5000 I/O Modules
5069-AENTR Adapter
Compact 5000 I/O Modules
1734-AENTR Adapter
1734 POINT I/O Modules
PowerFlex 527 Drive Kinetix 5500 Drives
Stratix® 5700 Switch
PanelView Plus 7 Terminal
Workstation
