Allen-Bradley CompactLogix 5480 User Manual

Rockwell Automation Publication 5069-UM002A-EN-P - January 2019 269
Troubleshoot the Controller Chapter 11
Advanced Diagnostics Webpages
The Advanced Diagnostics webpages provide information about
the following:
• TCP/IP Network - Provide information about the following:
– ICMP Statistics
– IP Statistics
– UDP Statistics
– TCP Statistics
– TCP Connection
–UDP Table
• Ethernet Port A1, A2, and B1 - Provide information about
the following:
– Interface Statistics
–ARP Table
– IP Route Table
• 1588 PTP (Time Sync)
The Ethernet port webpages are shown as follows:
•
Figure 61 shows the Advanced Diagnostics webpage when the
controller is in Linear/DLR mode.
•
Figure 62 shows the Advanced Diagnostics webpage when the
controller is in Dual-IP mode.
IMPORTANT This information is listed separately for, and is unique to, each port
when the controller operates in Dual-IP mode.
