68 Rockwell Automation Publication 5069-UM002A-EN-P - January 2019
Chapter 2 Connect to the Controller
9. On the Online toolbar, click the Controller Properties icon.
10. On the Internet Protocol tab, choose the port from the Port pull-down
menu.
11. Click Manually configure IP settings, enter the necessary values, and
click Apply.
12. If a dialog box appears to confirm the change, click Yes.
Use a Secure Digital Card to Set the Controller IP Address
You can use an SD card to set the controller IP address. The SD card can set the
IP address when it loads a project onto the controller.
For more information on how to use an SD card, see Chapter 4,
Use the Secure
Digital Card on page 101.
