Rockwell Automation Publication 5069-UM002A-EN-P - January 2019 141
Connect to Different EtherNet/IP Network Levels Chapter 6
You set the IP Address and Subnet Mask on the Internet Protocol tab.
1. Confirm that the project is online.
2. Confirm that the controller is in one of the following modes:
• Program mode
• Remote Program mode
• Remote Run mode
You cannot change the IP Address or Subnet Mask if the controller is in
Run mode.
3. Access the Controller Properties dialog box.
4. On the Internet Protocol tab, click Manually configure IP settings.
5. From the Port pull-down menu, choose A1/A2.
6. Assign IP Address and Network Mask values, and click Apply.
