Diagrams
4.1 Notes
NOTE
Indicates practical tips and instructions that will help
you
to make optimal use of all the functions of your
implement.
4.2 Instructions
Numbered instructions
Actions that have to be performed in a chronological
sequence
are represented as numbered instructions.
Always observe the sequence of the instructions. The
reaction to the respective action is marked with an arrow.
1. Action 1
Implement reaction to Action 1
2. Action 2
Instructions with alternative action
Alternative instructions are introduced with the word "or".
Example:
1. Action
or
Alternative action
2. Action
Instructions with only one action
Instructions with only one action are not numbered, but
rather shown with a tilted
arrow
Action
021149
021152
021150
021156
021153
021154
A | About this operating manual | Diagrams
MG5574-EN-II | B.1 | 25.10.2016
