Instructions without sequence
Instructions that do not require a specific sequence are
shown
as a list with tilted arrows.
Action
Action
Action
4.3 Lists
Lists are used, for example, to show different selection
options.
Entries in lists are introduced with points.
Example:
Entry 1
Entry 2
Entry 3
4.4 Item numbers
Item numbers in the text or in the legend refer to item
numbers in
figures located beside or above the text. The
item numbers in the figures can be connected with item
lines.
Item 1
Item 2
Item 3
4.5 Orientation paths
Orientation paths located at the beginning of text
sections with
instructions for action help with rapid
021155
007273
007274
021157
A | About this operating manual | Diagrams
MG5574-EN-II | B.1 | 25.10.2016
6
