5.3 If Trouble Occurs
HA-8190V 5-17
T-360 - T-362
T-371
Magnetic valve
Drain flow
Cause  Tubes inside the instrument are disconnected or improperly connected.
 The dilution container is contaminated.
 The dilution container is clogged.
 The magnetic valve did not operate properly.
Remedy a Touch to clear the trouble.
b Properly connect the tubes of the dilution unit (see page 4-40) and drain pinch valves
(see page 5-35).
c Clean the dilution container (see page 4-36).
d Disassemble and wash the dilution container (see page 4-39).
e If the trouble persists, turn off the power and contact your distributor.
T-373 - T-375 Drain flow
Cause  Tubes inside the instrument are disconnected or improperly connected.
 The dilution container is contaminated.
 The dilution container is clogged.
 The magnetic valve did not operate properly.
 The drain pump did not operate properly.
Remedy a Touch to clear the trouble.
b Properly connect the tubes of the dilution unit (see page 4-40) and drain pinch valves
(see page 5-35).
c Clean the dilution container (see page 4-36).
d Disassemble and wash the dilution container (see page 4-39).
e If the trouble persists, turn off the power and contact your distributor.
T-400 - T-402 Temperature sensor
Cause  There is a problem with the temperature sensor.
Remedy Turn off the power and contact your distributor.
T-403 - T-411 Temperature control
Cause  The room temperature is outside the measurement environment temperature range of between
10°C and 30°C.
 The temperature controlling unit did not operate properly.
Remedy a Touch to clear the trouble.
b Adjust the room to a temperature between 10°C and 30°C.
c If the trouble persists, turn off the power and contact your distributor.
T-420
T-430, T-431
T-432 - T-435
T-436 - T-439
Degasser unit
Fluid pump drive
Sample introduction valve
Eluent switching valve
Cause  The indicated part did not operate properly.
Remedy a Touch to clear the trouble.
b Turn off the power and contact your distributor.
T-450 - T-452 Excessive pressure
Cause  The column or tube is clogged.
Remedy a Touch to clear the trouble.
b Replace the column with the dummy column (see page 4-56) and pump fluid (see page 4-52: On
the [Priming menu] screen, select <2. Pump>). After five minutes, touch . The dummy
column was attached to the column installation position at the time of shipment.
c If fluid pumping finishes without any problem, replace the column with a new one
(see page 4-11).
d If the trouble persists, turn off the power and contact your distributor.
OK
OK
OK
OK
OK
Stop
