SIP User's Manual 46 Document #: LTRT-83310
Mediant 600 & Mediant 1000
3.1.6.5.2 Enhanced Design Tables
The enhanced table structure includes the following buttons:
Add: adds a row entry to the table
Edit: edits the selected table row
Delete: deletes a selected table row
View/Unview: shows or hides all configuration settings of selected table rows
To add an entry:
1. Click the Add button; the Add Record dialog box appears:
Figure 3-13: Add Record Dialog Box
2. Configure the required parameters, and then click Submit to apply your changes (or
Cancel to ignore your changes); the new row entry is added to the table. If the
configuration is invalid, the index of the table row is highlighted in red, as shown
below:
Figure 3-14: Index Highlighted in Red
By default, the table displays 10 entries per page. However, you can change this to 5 by
selecting 5 from the drop-down list located immediately below the table. If your table spans
over multiple pages, you can navigate between the pages by clicking the left and right
arrow buttons located immediately below the table.
