Appendix 1, Technical Data
MC4 User Guide 197
Type G
(6
Full Range: 0 ... 2315 °C
Sub Range Resolution 1 Year Uncertainty
(1
(±)
0  70 0.01 °C
(3
70  200 0.01 °C 1.0 °C
200  1600 0.01 °C 0.5 °C
1600  2000 0.01 °C 0.7 °C
2000  2315 0.01 °C 1.0 °C
Type D
(5
Full Range: 0 ... 2315 °C
Sub Range Resolution 1 Year Uncertainty
(1
(±)
0 ... 1000 °C 0.01 °C 0.4 °C
1000 ... 2000 °C 0.01 °C 0.04 % rdg
2000 ... 2315 °C 0.01 °C 1.2 °C
Thermocouple Types Available as Option
• K+/Au0.07Fe
(6
• Au/Pt
(6
• Ir40Rh/Ir
(6
• Ni18Mo/Ni0.8Co
(6
• Pt40Rh/Pt20Rh
(6
• Pt5Mo/Pt0.1Mo
(6
• Platinel II
(6
Internal Reference Junction
Range 1 Year Uncertainty
(1
(±)
-10 ... 50 °C 0.25 °C
1)
Uncertainty includes reference standard uncertainty, hysteresis, nonlinearity,
repeatability and typical long term stability for mentioned period. (k=2).
Uncertainty does not include reference junction uncertainty.
3)
±0.02 % of thermovoltage + 4 µV
5)
ASTM E 988 - 96
6)
ASTM E 1751 - 95e1
