Tools Menu
74 MC4 User Guide
The following table presents the fields of the configuration window.
FIELD DESCRIPTION/OPTIONS
Range
(
*
The minimum and maximum value for the
stepping range.
Step Time
Enter the time for a single step. Use only
full seconds, no decimals.
Repeats
Defines how many times the steps are
repeated. Value "zero" equals continuous
stepping.
Repeat Format
How the stepping should be done.
Available options:
Up / Down
Down / Up
Up
Down
Step Definition
Defines how the stepping is done
Available options (with no custom sets):
By: 'Step Size'
By: 'Number of Steps'
3: 50 %
5: 25 %
6: 20%
11: 10 %
0%>10>25>50>75>90>100
0%>2>4>50>96>98>100
0%>5>40>100
-2%>0>2>4>50>96>98>100>102
Create New…
The two first options require additional
data that is entered in the two following
fields.
The group of sets starting with a number
and colon are sets with fixed step sizes.
The first number is the amount of step
levels and the percentage value is the
step size.
The group of sets starting with a number
and percentage symbol are sets with
varying step sizes (suitable for, e.g. valve
tests). Each number is a step level.
The last item in the list allows you to
make your own custom step definition.
Custom steps are presented in chapter
Custom Test Point Sets on page 101.
Continues on next page
