Belarus 82.3 - Page 125

82.3-0000010 OM
125
Table 4.4.14 finished
Travel speed,
km/h,
not more
Vertical load for tow hitch, kg, not more
Tow hook
K1220-2807005
Non-rotating
yoke
1321-2707111-А
5)
Non-rotating
yoke
1321-2707113-А
5)
Automatic
rotating yoke
1321-2707050-B1
5)
Automatic
rotating yoke
Sharmuller art.
03.3313.221
5)
Non-automatic rotat-
ing yoke
2422-2707110
With rear tires 15,5R38
10
1850,1
1820,2 (1000)
1850,1 (1000)
1200 (800)
1814 (1000)
1000
20
1778,2
1749,4 (1000)
1778,2 (1000)
1200 (800)
1743,7 (1000)
1000
30
1234,7
1214,7 (1000)
1234,7 (1000)
1124,4 (800)
1210,8 (1000)
1000
40
1003,0
986,7 (986,7)
1003,0 (1000)
913,4 (800)
-
981
With rear tires 18,4R34
10
1850,1
1820,2 (1000)
1850,1 (1000)
1200 (800)
1814 (1000)
1000
20
1850,1
1820,2 (1000)
1850,1 (1000)
1200 (800)
1814 (1000)
1000
30
1850,1
1820,2 (1000)
1850,1 (1000)
1200 (800)
1814 (1000)
1000
40
1850,1
1820,2 (1000)
1850,1 (1000)
1200 (800)
1814 (1000)
1000
With rear tires 9.5-42
4)
10
1663,1
1636,1 (1000)
1663,1 (1000)
1200 (800)
1630,8 (1000)
1000
20
1078,9
1061,4 (1000)
1078,9 (1000)
982,5 (800)
1058,0 (1000)
1000
30
-
-
-
-
-
-
40
-
-
-
-
-
-
1)
– For tractor weighing 5060 kg (with the tire inner pressure making 160 kPa); rear PTO projection 500mm from rear wheels (with brack-
et 1321-2707060B-02/-03: for tow hitch installation).
2)
– The draw bar is used for coupling of agricultural equipment at maximum travel speed of 30 km/h.
3)
– The crossbar (single) and the twin crossbar are used for coupling of agricultural machines at travel speeds of max. 15 km/h and are
not intended for being used in public roads. The main load value for the twin crossbar is given for the position of the connecting link axis
relative to the rear PTO shaft making 320 mm, in brackets respectively – the first value for 400 mm and the second for 480 mm. Regard-
ing load values of the crossbars (single and twin) for 15 km/h, the load values indicated for 20 km/h shall be applied.
4)
– Tires for rear wheels of standard size 9.5-42 shall be used on the tractor only within the twinned configuration at the speed of max. 20
km/h.
5)
– For tow hitches 1321-2707113-A; 1321-2707050-B1 and Sharmuller art. No. 03.3313.221, permissible values of the loads when the
specified tow hitches are located above the axis of the rear PTO shaft end are given in brackets.
