4.13.3 Information on tractor mounting holes
This subsection presents data on availability of tractor mounting holes which can be
used by manufacturers of front loaders for loader installation, and also by the tractor manufac-
turer for installation of various equipment. The mounting hole arrangement scheme for the
BELARUS-82.3 tractors is shown in figure 4.13.2. Parameters of mounting holes are listed in
table 4.13.2.
Table 4.13.2 – Parameters of mounting holes of the BELARUS-82.3 tractors
Designation
№ 1
№ 2
№ 3
№ 4
№ 5
Diameter
M16
M16
M16
M16
M16
Length of thread
20
14
20
14
15
Designation
№ 6
№ 7
№ 8
№ 9
№ 10
Diameter
M16
M16
M16
M16
M16
Length of thread
20
15
24
15
20
Designation
№ 11
№ 12
№ 13
№ 14
№ 15
Diameter
M16
M16
M16
M16
M16
Length of thread
15
20
20
20
20
Designation
№ 16
№ 17
№ 18
№ 19
№ 20
Diameter
M16
M16
M16
M16
M16
Length of thread
20
38
32
38
32
Designation
№ 21
№ 22
№ 23
№ 24
№ 25
Diameter
M16
M16
M16
M16
M16
Length of thread
38
32
32
32
32
Designation
№ 26
№ 27
№ 28
№ 29
№ 30
Diameter
17
M16
M16
M16
M16
Depth
174
35
35
35
35
Designation
№ 31
№ 32
№ 33
№ 34
№ 35
Diameter
M16
M16
M16
M16
17
Depth
23
23
23
23
174
Designation
№ 36
№ 37
№ 38
№ 39
№ 40
Diameter
17
22
22
M16
17
Depth
174
53
53
174
174
Designation
№ 41
№ 42
№ 43
№ 44
№ 45
Diameter
М27
М27
М27
М27
18
Depth
55
55
55
55
14
Designation
№ 46
№ 47
№ 48
№ 49
№ 50
Diameter
18
18
M14
18
M14
Depth
14
14
14
14
14
NOTES:
Sizes in Table 4.13.2 are given in mm.
Holes 1…30 are right and left.
In course of installation of mounted components ensure safety of bushings in holes 1, 8 and
12.
ATTENTION: IT IS NOT RECOMMENDED TO USE TRACTOR SIDE HOLES WITH BUSH-
INGS! MOUNTED LOADER COMPONENTS MUST NOT CAUSE DESTRUCTION OF BUSHINGS!
