78
IFS 125M User Manual Bruker Optik GmbH
Maintenance 6
5 • Two persons are required to put down the
cover of the long scanning arm, one at the
front and one at the back end.
• Put your hands below the hangers.
Cover not put down properly.
Risk of scanner damage.
➣ Put down the cover straight and far
downwards.
6 Close the clips on each side.
a. If the pretension of any clip is too high or too low, it can be adjusted by turning the metallic screw nut with
a pipe wrench in the appropriate direction.
Table 6.5: Adjusting laser - Remounting covers
