IFS 125M User Manual Bruker Optik GmbH
Maintenance 6
• Insert the O-ring (B) into the window flange (A).
• Put the window (C) onto the O-ring in the window flange. Always wear gloves.
• Position the distance ring (D), if applicable.
• Position the O-ring (E) into the fixation ring (F).
• Put the fixation ring (F) onto the window assembly.
• Use a hexagon socket setscrew (2 mm) to gradually tighten the screws one after
the other.
C Window
D Distance ring (only required for thin win-
dow types)
E O-ring for fixation ring (F)
F Fixation ring
G Window port cover
Definition
Table 6.12: Parts of window assembly
CAUTION
Damaged window:
Risk of breaking.
➣ Never insert a window which shows signs of damage.
➣ Never insert a window thinner than specified.
