Brunswick Sync - Page 121

Sync Scorer Components 89
(1)
TO
NETWORK SWITCH
(UNDER APPROACH)
(2)
TO
NETWORK SWITCH
ON POWER SUPPLY
(CURTAIN WALL)
Power Cable - Table Ethernet Switch (Part No. 57-501333-000)
(1) TO NETWORK SWITCH (2) TO NETWORK SWITCH ON
(UNDER APPROACH) POWER SUPPLY (CURTAIN WALL)
Foul Cable (Part No. 57-501378-000)
(1) TO DISTRIBUTION BOARD J5 (2) LEFT FOUL + (3) LEFT FOUL -
(4) RIGHT FOUL + (5) RIGHT FOUL - (6) GROUND
(7) OR +12 VOLTS DIRECT (8) RIGHT (9) LEFT
CURRENT
(10) TO FOUL UNIT RIGHT OUTPUT (11) TO FOUL UNIT LEFT OUTPUT
1
2
3
57-501379-000
3
2
1
3
2
1
LEFT
RIGHT
3
2
1
RIGHT- BALL DETECT
LEFT- BALL DETECT
BLACK
GREEN
RED
BLUE
ORANGE
WHITE
GREEN
RED
BLACK
BLUE
ORANGE
WHITE
(1)
TO
DISTRIBUTION
BOARD
J27
+12V DC
LEFT B.D.
GND
RIGHT B.D.
GND
+12V DC
(2)
TO
DISTRIBUTION
BOARD
J32
(4)
TO
BALL DETECT
RIGHT LANE
(3)
TO
BALL DETECT
LEFT LANE
Camera Ball Detect Cable (Part No. 57-501379-000)
(1) TO DISTRIBUTION BOARD J27 (2) TO DISTRIBUTION BOARD J32 (3) TO BALL DETECT LEFT LANE
(4) TO BALL DETECT RIGHT LANE
