Brunswick Sync - Page 122

90 Sync Scorer Components
Peripheral Controller to Pinball Wizard Bumpers (Part No. 57-501384-000)
(1) TO LLAN IN ON AUTOMATED (2) TO “BUMPER” ON DISTRIBUTION
CONTROLLER PCB PERIPHERAL CONTROLLER
GS-Pinsetter Direct Connect Data Cable (Part No. 57-501385-000)
(1) TO “GS PINSETTER” ON (2) SHELL (3) DRAIN
PERIPHERAL CONTROLLER
(4) NO CONNECTION (5) LAN A (6) LAN B
(7) +12 VOLTS DIRECT CURRENT (8) GROUND (9) CHASSIS
(10) TO P8 (COMLINE IN) ON GS-98
DIRECT OR P8 (SCORER COMLINE IN) ON GS-X
BLK
BLK
BLK
BLK
NC
BLK
BLK
BLK
BLK
BLK
BLK
BLK
BLK
BLK
NC
BLK
BLK
BLK
BLK
NC
(2)
TO GS
FOUL/BALL DETECT
CABLE
(47-142672-000)
BLK
(3)
TO DB7 PCB
LEFT/ RIGHT
BALL DETECT
(J27/J32)
RED
BLK
(1)
TO GS
ELECTRICAL ENCLOSURE
BOX (P4/P20)
BLK
RED
2
3
1
9
10
1
8
7
6
5
4
2
3
9
10
1
8
7
6
5
4
2
3
GS-Pinsetter Ball Detect Cable (Part No. 57-501391-000)
(1) TO GS ELECTRICAL (2) TO GS FOUL/BALL DETECT (3) TO DB7 PCB LEFT/RIGHT BALL
ENLCOSURE BOX (P4/P20) CABLE (47-142672-000) DETECT (J27/J32)
