34
Sync Camera Assembly
CAUTION! The ball detect jumper on the Distribution board MUST be set to
the proper voltage. Failure to do so can cause permanent damage to the ball
detector.
Square Ball Detector - Install jumper at pins 1-2 (5V)
Round Ball Detector - Install jumper at pins 2-3 (12V)
(3) Watchdog Enable - (JP12) For factory use only.
JP12 - Remove jumper (Default)
(4) Foul - (JP18) Jumper used to congure the distribution so that is can properly handle the
foul input signal. When using Brunswick foul units or foul units that use a relay type (switch)
output, install a jumper to short the pins. If using a foul unit that supplies +12VDC as an output
(AMF) remove the jumper.
Brunswick Foul Unit - Install jumper (Default)
AMF Foul Unit - Remove Jumper
(5) Spare Power - (JP16) Reserved for future use.
JP16 - Remove Jumper (Default)
(6) +12V Isolation - (JP10) Factory use only.
JP10 - Install Jumper (Default)
(7) RS-485 (LAN) Termination - (JP3,JP6,JP7) Jumpers used to terminate the RS-485
communication.
JP3 - GS pinsetter communication. Install jumper at pins 2-3 (Terminate) (Default)
JP6 - Brunswick automated bumpers. Install jumper at pins 2-3 (Terminate) (Default)
JP7 - Spare. Install jumper at pins 2-3 (Terminate) (Default)
(8) Camera Port Power (JP19) - Selects voltage level used for the cameras.
Install jumpers at pins 2-3 (+12V).
(9) LAN3 Communication Type (JP20) - Determines the communication protocol used for LAN3
(J18).
Default - Install jumper at pins 2-3 (RS232)
Intellishield controller connected to LAN3 - Install jumper at pins 1-2 (RS485)
(10) Reset - (SW1) Push button used to restart the Distribution board.
(11) Digital Camera Enable - (JP8) Factory use only.
JP8 - Install Jumper (Default)
(12) Memory Conguration - (JP14,JP15) Factory use only.
JP14 - Install jumper at pins 1-2 (Default)
JP15 - Install jumper at pins 1-2 (Default)
