FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
5
MAINTENANCE
ORIGINAL INSTRUCTIONS 143
THS/FB
Unlock the belt by raising the idle roller
support
Extract the idle roller from the side
supports
Pull the idle roller out of the belt
Raise the support surface from its position
and pull it out of the belt
Pull the other roller out of the side supports Remove the roller from the belt
Raise the support surface from its position Pull the surface out of the belt, which is
now free and ready to be cleaned
To refit the belt, follow this procedure in
reverse order.
Crushing and cutting hazard. When you are positioning the support surface on the entrance side, take precautions to
prevent the risk of crushing and cutting between the surface and the belt frame.
