CI Systems SR-800R
8.4.3 Connecting Pipes to the Julabo Circulation System
Mount the Pipes and fasten using a 19 mm open-wrench:
Figure 8-8: Connecting Pipes to the Julabo Circulation System - Fastening the Pipes
19 mm
Open Wrench
605-7040 Operation Manual
Rev D 8-12
June 2013
