Chapter 66 Configuring Ethernet OAM and CFM
Managing and Displaying Ethernet CFM Information
You can use the privileged EXEC commands in Table 66-2 to display Ethernet CFM information.
This is an example of output from the show ethernet cfm domain brief command:
Switch# show ethernet cfm domain brief
Domain Name Index Level Services Archive(min)
level5 1 5 1 100
level3 2 3 1 100
test 3 3 3 100
name 4 3 1 100
test1 5 2 1 100
lck 6 1 1 100Total Services : 1
This is an example of output from the show ethernet cfm errors command:
Switch# show ethernet cfm errors
--------------------------------------------------------------------------------
MPID Domain Id Mac Address Type Id Lvl
MAName Reason Age
--------------------------------------------------------------------------------
6307 level3 0021.d7ee.fe80 Vlan 7 3
vlan7 Receive RDI 5s
This is an example of output from the show ethernet cfm maintenance-points local detail command:
Switch# show ethernet cfm maintenance-points local detail
Local MEPs:
----------
MPID: 7307
DomainName: level3
Level: 3
Direction: Up
Vlan: 7
Interface: Gi0/3
CC-Status: Enabled
CC Loss Threshold: 3
MAC: 0021.d7ef.0700
LCK-Status: Enabled
LCK Period: 60000(ms)
LCK Expiry Threshold: 3.5
Table 66-2 Displaying CFM Information
Command Purpose
show ethernet cfm domain [brief]
Displays CFM domain information or brief domain information.
show ethernet cfm errors [configuration |
domain-id]
Displays CFM continuity check error conditions logged on a device since
it was last reset or the log was last cleared. When CFM crosscheck is
enabled, displays the results of the CFM crosscheck operation.
show ethernet cfm maintenance-points local
[detail | domain | interface | level | mep
| mip]
Displays maintenance points configured on a device.
show ethernet cfm maintenance-points
remote [crosscheck | detail | domain |
static]
Displays information about a remote maintenance point domains or levels or
details in the CFM database.
show ethernet cfm mpdb
Displays information about entries in the MIP continuity-check database.
show ethernet cfm smep [interface
interface-id
]
Displays Ethernet CFM SMEP information.
show ethernet cfm traceroute-cache
Displays the contents of the traceroute cache.
