CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–34 MN-CDM570A
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
G.703 Clock
Extension
CEX
2 byte
Command or Query.
Sets or returns G.703 Clock Extension in the form ab, where:
a = G.703 Clock Extension Mode (0=None; 1=TxLock; 2=RxEnable)
b = G.703 Clock Extension Interface (0=T1; 1=E1Bal; 2=E1Unbal)
Notes:
1) Not all CEX modes are valid all the time.
2) For argument a:
• When Data Interface (ITF) is set to be G.703, Clock Extension Mode is
automatically set to be 0=None. Response is ITF+
• When Tx Clock (TCK) is changed from Internal to Non-Internal, Clock
Extension Mode will be automatically changed to 0=None if it was
1=TxLock. Response is TCK+
Example: <0/CEX=12 (Sets Tx Lock to E1 Unbalanced)
CEX=
CEX?
CEX*
CEX#
CEX?
CEX=ab
(see Description of
Arguments)
T1 Line
Build-Out
LBO=
1 byte,
value of 0 thru 4
Command or Query.
Valid only for T1 interface (in all modes other thanT1, this is a don’t care),
Sets or returns T1 Line build-out in the form x, where
0 = 0-133 feet
1 = 133-266 feet
2 = 266-399 feet
3 = 399-533 feet
4 = 533-655 feet
Example: <0/LBO=2
LBO=
LBO?
LBO *
LBO #
LBO?
LBO=x
(see Description of
Arguments)
Tx BERT
State
BTX=
1 byte, value of
0 or 1
Command or Query.
Valid only in CDM-570A Compatible Mode (CMO=1).
Sets or returns Tx BERT State in the form x, where:
0 = Off
1 = On
Example: <0/BTX=1 (Tx BERT On)
BTX=
BTX?
BTX#
BTX?
BTX=x
(see Description of
Arguments)
Rx BERT
State
BRX=
1 byte, value of
0 or 1
Command or Query.
Valid only in CDM-570A Compatible Mode (CMO=1).
Sets or returns Rx BERT State in the form x, where:
0 = Off
1 = On
Example: <0/BRX=1 (Rx BERT On)
BRX=
BRX?
BRX#
BRX?
BRX=x
(see Description of
Arguments)
