CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–36 MN-CDM570A
Parameter
Type
(Instruction
Code and
Qualifier)
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
in average
BER
Valid only in CDM-570A Compatible Mode (CMO=1).
Returns the value of the average BER in the form x.xxEsyyl, where:
First 8 bytes are the value.
Last byte is the indicator of Sync Loss. A ‘*’ in last byte means there was a loss
of pattern synchronization since last restart, but now is synchronized. A ‘_’
(space) in last byte means pattern synchronization is achieved.
Returns 999999999 if there’s no sync in BERT monitor.
Examples: <0/BRR?
1) >0/BRR=2.80E-07 (BER is 2.80 x 10
-7
, in sync)
2) >/BRR=3.40E-05* (BER is 3.40 x 10
-5
, and there was a Sync Loss)
parameters
Valid only in CDM-570A Compatible Mode (CMO=1).
Sets or returns ACM operating parameters in the form mMAT, where:
VersaFEC ACM (IP-ACM):
m=Minimum ModCod, range is 0 to 9, and A (for ModCod=10) or B (for
ModCod=11)
M= Minimum ModCod, range is 0 to 9, and A (for ModCod=10)or B (for
ModCod=11)
A= Defines action on remote demod unlock
0 = go to minimum Tx ModCod
1 = maintain Tx ModCod
T=Target Eb/No Margin, from 0 to 9 that is two times the Eb/No in dB (from
0.0dB to 4.5dB).
VersaFEC-2 ACM (V2-ACM):
mM=Maximum Tx ModCod in decimal, range is 00-37 for Long block, and
00-35 for Short Block.
A=Action on remote demod unlock (0=go to Tx ModCod 0)
T=Target Eb/No Margin, from 0 through 9 that is two times the Eb/No in dB
(from 0.0dB to 4.5dB).
Example: <0/ACM=0B12 (Sets min ModCod=0; max ModCod =11; maintains Tx
ModCod when remote demod unlocks; sets Target Eb/No at 1.0dB.)
ACM?
ACM#
(see Description of
Arguments)
Directs the CDM570AL to retrieve a previously stored modem configuration from
the Configuration Memory location 0 through 9.
Example: <0/CLD=4 (retrieves modem configuration from location 4)
CLD?
CLD*
