CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–42 MN-CDM570A
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Global
Configuration in
CDM-570
Compatible Mode
(CMO=0)
(continued)
rr = G.703 Clock Extension
sssss = expansion bytes
AAAA.AAAA = Rx Frequency
B = Rx FEC Typ
C = Rx Modulation Type
D= Rx FEC Rate
EEEE.EEE = Rx Data Rate
F = Rx Spectrum Inversion
G = Rx Descrambler state
H = Rx Data Invert
III = Rx Sweep Width
JJ.J = Eb/No Alarm Point
K = Rx Buffer Size
LLLLLLLL = expansion bytes
M = External Reference Frequency
N = EDMAC Framing Mode
OOOO = EDMAC Slave Address
P = Unit test Mode (Read only)
QQQQQQQQQQQQ = Unit Alarm Mask
R=RTS/CTS Control
S = Statistics Sampling Interval
T = Attach BUC Alarm to Tx Alarm
U = Attach LNB Alarm to Rx Alarm
VVVVVV = expansion bytes
Fill unused expansion bytes with ‘x’
same as CEX
same as RFQ
same as RFT
same as RMD
same as RCR
same as RDR
same as RSI
same as RDS
same as RDI
same as RSW
same as EBA
same as RBS
same as ERF
same as EFM
same as ESA
same as TST
same as MSK
same as RTS
same as SSI
same as ABA
same as ALA
