CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–51 MN-CDM570A
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Faults and
Status
N/A
6 bytes
Query only.
Returns the current highest-priority fault and status codes for the Unit
(hardware), Tx Traffic, Rx Traffic and ODU in the form abcdef, where:
a = Unit faults:
0 = No faults
1 = Power supply fault, +5 volts
2 = Power supply fault , +12 volts
3 = Power supply fault, –5 volts
4 = Reserved
5 = Power supply fault, –12 volts
6 = Tx synthesizer lock
7 = Rx 1st LO synthesizer lock
8 = Rx 2
nd
LO synthesizer Lock
9 = Ref PLL lock
A = Reserved
B = Reserved
C = Reserved
D = Reserved
E = Packet Processor
F = Reserved
b = Tx Traffic status:
0 = Tx traffic OK
1 = No clock from terrestrial interface
2 = Tx PaP ETH Link Down
3 = Tx FIFO slip
4 = G.703 Loss of Signal (valid only in Clock Extend Mode)
5 = Loss of External Reference
6 = Reserved
7 = AUPC upper limit reached
8 = Reserved
9 = AIS detected on incoming data
A = Reserved
B = Bipolar violation on G.703 interface
C = Reserved
D = Reserved
E = Reserved
F = BUC Alarm (if attached)
N/A
FLT?
FLT=abcdef
(see Description of
Arguments)
