CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Optional Packet Processor - Serial/Telnet CLI Operation 9–65 MN-CDM570A
Unit Uptime [RO]
Displays – in days, hours, mins, and secs – the lapsed time since the
modem and Packet Processor were last rebooted.
Displays the operating firmware information page.
Select which Packet Processor firmware image (includes Application,
FPGA, and FFPGA) is loaded upon bootup:
0 – Latest: Boot the newer firmware image based upon date.
1 – Image1: Boot the firmware image loaded into the first slot in
permanent storage.
2 – Image2: Boot the firmware image loaded into the second slot in
Select which Packet Processor or Base Modem firmware image
(includes Application, FPGA, and FFPGA) is overwritten in the Firmware
Update FTP process:
0 – Oldest: Updates the older firmware image based upon date.
1 – Image1: Updates the firmware image loaded into the first slot in
permanent storage.
2 – Image2: Updates the firmware image loaded into the second slot
Select which Base Modem firmware image is loaded upon bootup. The
possible options are:
0 – Latest: Boot the newer firmware package based upon date.
1- Image1: Boot the firmware image loaded into the first slot in
permanent storage.
2 – Image2: Boot the firmware image loaded into the second slot in
Codecast Multicast Address
Set the Multicast address used by VLOAD to upgrade the modem
firmware and param file via streaming Multicast. Must match the
address specified in VLOAD.
Select the PARAM file that is loaded on bootup:
1 – Last saved Parameter file
2 -Factory – uses the internal, hard-coded factory default parameters.
Displays the Statistics page.
Displays the Event Log page.
Displays the Database Operations page.
Reboots the modem (including the Packet Processor). It has the same
logical effect of power-cycling the unit.
Displays the Diagnostics page.
Allows base modem communications debugging.
