CDM-570L/570AL Satellite Modem with Optional Packet Processor

Revision 5

Optional High Performance Packet Processor D–7 MN-CDM570A

Step

Task

Use the screwdriver to reinstall the top cover onto the

CDM-570A/570AL chassis with its existing mounting

hardware.

Plug the modem’s power cord back into its power

source.

The High-Performance Packet Processor upgrade is now complete. You may turn on and resume use of the

modem.
