CDM-570L/570AL Satellite Modem with Optional Packet Processor

Revision 5

Optional High Performance Packet Processor D–6 MN-CDM570A

Step

Task

Use the screwdriver to secure the Packet Processor

card to the chassis with its provided mounting

hardware (4X 4-40 x 1/4 pan head screws).
