SLM-5650B Satellite Modem
Revision 2
Front Panel Operation 5–23 MN-SLM-5650B
Option Settings
Select
if the optional Network Processor is not plugged in;
, select the Network
Processor Working Mode:
• RtrVSHub
• RtrVSHEx
• RtrVSRem
• RtrVSREx
• RtrMPHub
• RtrMPRem
• RtrPtop
• Bridge
When selecting an IF frequency band, both transmit and receive operate in the selected
band. Operation of transmit in one IF frequency band and the receive in the other IF
frequency band is not permitted.
When selecting a data interface type, a native interface can be selected even if an
optional interface is installed, but an optional interface can only be selected if it is
installed. Both transmit and receive must use the selected interface type. Transmitting
using one interface type and receiving using another interface type is not permitted.
