SLM-5650B Satellite Modem
Revision 2
Network Processor (NP) Interface 8–25 MN-SLM-5650B
8.6.5.3 Modem Page
Use the Modem pages to configure or view the primary Transmit parameters and primary Receive
parameters of the SLM-5650B Satellite Modem.
Select the Config, Monitor, Events, Stats, or Utility hyperlink to continue.
Figure 8-19. Modem | Config (Modem Configuration) Page
8.6.5.3.1 Modem | Config (Modem Configuration)
Modem Operating Mode
Modem Type (read-only)
Modem Type Description
OM-73 Linkabit OM-73 modem compatibility mode.
MIL-165A Functionality defined by MIL-STD-188-165A.
IESS-308 Functionality defined by IESS-308, the Intelsat Intermediate Data Rate standard.
IESS-309 Functionality defined by IESS-309, the Intelsat Business Services standard.
IESS-310 Functionality defined by IESS-310, the Intelsat 8-PSK Intermediate Data Rate standard.
TURBO Functionality defined by IESS-315 plus Comtech EF Data Turbo mode interoperability.
16-QAM 16-QAM is selected as a modulation type.
AUPC Automatic Uplink Power Control is used.
TX-BURST The unit is a Vipersat Remote Modem.
RX-BURST The unit is a Vipersat STDMA Hub Modem with its Acquisition Mode set to “Standard.”
RX-BURST-FA The unit is a Vipersat STDMA Hub Modem with its Acquisition Mode set to “Long”.
TURBO-FA The unit is a Vipersat Hub Expansion Modem.
