SLM-5650B Satellite Modem
Revision 2
TRANSEC Module HTTPS Interface 10–13 MN-SLM-5650B
10.4.2.2 Transmit Status
Item Description
TX Frame Count
Displays the number of transmitted AES 256 frames.
TX Status
Describes the value of the Tx Status register.
DCM Lock
Displays the state of the Tx DCM lock.
Bypass Traffic
Displays the encryption status (
Bypass on
means Encryption off).
Crypto Traffic
When
Detected
, the module has sampled outgoing traffic and verifies it has been
encrypted. When Not Detected, encryption is off, or the module cannot verify
encrypted traffic.
10.4.2.3 Receive Status
Item Description
RX CRC Errors
Displays the count of received CRC errors.
RX Frame Count
Displays the number of received AES 256 frames.
RX Status Displays the value of the Rx Status register.
DCM Lock
Displays the state of the Rx DCM lock.
Unique Word Lock
Indicates that the decryption engine has successfully found the unique word and has
been able to lock to it.
Out of Sync
Indicates that an out-of-sync condition has been detected by the encryption engine.
10.4.2.4 Automatic Refresh Status Timer
The page updates itself automatically for the duration of the countdown timer. When the timer
reaches 0:00, the page will stop updating to help conserve system resources.
To manually override the timer, click Stop to interrupt or Reset to restart the timer.
