Comtech EF Data SLM-5650B - CONFIG  Mode

SLM-5650B Satellite Modem
Revision 2
Front Panel Operation 5–22 MN-SLM-5650B
5.2.3.3 CONFIG  Mode
Mode: Modem:MIL-165A FreqBand:L-Band
Interface:NetworkProc Mode:RtrPtop (E)
Use the  arrow keys to select Modem Type, FreqBand, Interface, or (when applicable)
the Network Processor Working Mode, and then press [ENT].
Use the  arrow keys to scroll through the available settings. Press [ENT] once again
when done.
Option Settings
Modem
• MIL-165A – Select functionality defined by MIL-STD-188-165A.
• OM-73 – Select Linkabit OM-73 modem compatibility mode.
• SLM-9000C – This is a future option.
• IESS-308V2 – This is a future option.
• LDPC – Select Low Density Parity Check and Spreading.
• RXBRSTFA – Not Available.
• TURBO-FA – Not Available.
• TXBURST – Not Available.
• RXBURST – Not Available.
• AUPC – Automatic Uplink Power Control.
• 16QAM – Select 16-QAM as a modulation type.
• TURBO – Select functionality defined by IESS-315 plus Comtech EF Data Turbo mode
interoperability.
• IESS-310 – Select functionality defined by IESS-310, the Intelsat 8-PSK Intermediate Data
Rate standard.
• IESS-309 – Select functionality defined by IESS-309, the Intelsat Business Services
standard.
• IESS-308 – Select functionality defined by IESS-308, the Intelsat Intermediate Data Rate
standard.
FreqBand
• 70/140 MHz (52–88 MHz, 104–176 MHz);
• L-Band (950–2000 MHz).
Interface
• HSSI – Native interface (standard equipment).
• EIA-530 – Native interface (standard equipment).
• LVDS – Optional data interface.
• Network Processor – Optional data interface.
• ASI – Internal test interface (Not Available).
• GigaBit Ethernet – Optional data interface.
• G.703 (BAL) – Optional data interface.
• G.703 (UNBAL) – Optional data interface.
