2.2.1 Optional Rear Support Bracket Kit
Tools needed to install the Bracket Kit:
• A medium Phillips screwdriver
• A 5/32-inch SAE Allen Wrench
• An adjustable Crescent wrench.
To install the kit:
Step Description
1
Use the #10 flat washers, #10 split washers, and #10 hex nut to secure the #10 shoulder screws to the unit
chassis through the rear right and left side slots as shown.
2
Use the #10 rack bracket bolts to install the rear support brackets onto the rack enclosure threaded rear
rails.
3
Install the unit into the rack enclosure. Ensure that the shoulders of the #10 shoulder screws properly engage
into the rear support bracket slots.
