SLM-5650B Satellite Modem
Revision 2
Network Processor (NP) Interface 8–46 MN-SLM-5650B
8.6.5.7 Stats (Statistics) Page
Select the Ethernet Tx, Ethernet Rx, IP, WAN, or Clear All hyperlink to continue.
8.6.5.7.1 Stats | Ethernet Tx
Figure 8-33. Stats | Ethernet Tx Statistics Page
Clear/Refresh Ethernet Tx Stats
Click [Clear] to delete all Ethernet Tx statistics (this will also clear all Ethernet Rx statistics).
Click [Refresh] to update the page with the most recent statistics.
Tx Valid Frames
Column Description
Port
The corresponding Ethernet port on the NP Interface and, when in BPM Mode, the base
modem’s J5 Ethernet port.
Unicast Number of valid unicast frames transmitted.
Broadcast
Number of valid broadcast frames transmitted.
Multicast Number of valid multicast frames transmitted.
Pause Number of PAUSE frames transmitted.
