Appendix B B–13 MN-SLM-5650B
Modulation Type R-S Code Word R-S Depth
Data Rate (kbps) Symbol Rate (ksps)
Min Max Min Max
OQPSK 1/2
225,205
8
256
25625
74.926
30000
OQPSK 3/4 225,205 8 256 38437.500 49.951 30000
OQPSK 7/8 225,205 8 256 44843.750 42.815 30000
8PSK 2/3
225,205
8
256
51250
149.853
30000
8PSK 5/6
225,205
8
256
51840
119.882
24276.292
16QAM 3/4 225,205 8 256 51840 99.902 20230.243
16QAM 7/8 225,205 8 256 51840 85.630 17340.209
B.1.11 AUPC Mode – Sequential
Modulation Type R-S Code Word R-S Depth
Data Rate (kbps) Symbol Rate (ksps)
Min Max Min Max
BPSK 1/2 OFF N/A 64 1171 136.533 2498.133
QPSK 1/2
OFF
N/A
64
2048
68.266
2184.533
QPSK 3/4 OFF N/A 64 2048 45.511 1456.355
QPSK 7/8 OFF N/A 64 2048 39.009 1248.304
OQPSK 1/2
OFF
N/A
64
2048
68.266
2184.533
OQPSK 3/4 OFF N/A 64 2048 45.511 1456.355
OQPSK 7/8
OFF
N/A
64
2048
39.009
1248.304
BPSK 1/2
225,205
8
64
1067
149.853
2498.341
QPSK 1/2 225,205 8 64 2048 74.926 2397.658
QPSK 3/4
225,205
8
64
2048
49.951
1598.439
QPSK 7/8 225,205 8 64 2048 42.815 1370.09
OQPSK 1/2 225,205 8 64 2048 74.926 2397.658
OQPSK 3/4
225,205
8
64
2048
49.951
1598.439
OQPSK 7/8 225,205 8 64 2048 42.815 1370.09
