SLM-5650B Satellite Modem
Revision 2
Network Processor (NP) Interface 8–4 MN-SLM-5650B
8.3 Interface Specifications
8.3.1 Physical Description
Dimensions
4.5 W x 6.8 D x .85 H inches (11.43 W x 17.27 D x 2.16H cm)
Connectors
Modem connection: (1) 96-pin DIN receptacle
Console interface for board bring-up and factory use only:
(1) RJ-11 connector
LAN interface: (4) RJ-45 female connectors, 100Ω
Indicators
Link Status and Activity Light-Emitting Diodes (LEDs)
8.3.2 General Specifications
Data Framing
10/100/1000Base-T Interface: RFC-894 “Ethernet”
Data Framing Format (WAN) CEFD proprietary
Electrical Properties
Per IEEE 802.3ab
Max Ethernet Frame 1518 Bytes (all modes)
Packet Types
Burst, distributed, or IPV4
Signal Types Serial data
Voltage Level
Per IEEE- 802.3ab
Packet Latency 50 ms maximum
Cable Length, Maximum
100 meters CAT 5 cable, patch cords and connecting hardware, per
ISO/IEC 11801:1995 and ANSI/EIA/TIA-568-A (1995)
Hot Pluggable
Card – No
Cable – Yes
