SLM-5650B Satellite Modem
Revision 2
Appendix C C–63 MN-SLM-5650B
C.6.9 Network Processor (NP) Interface Commands / Queries
The instruction codes that follow are valid only when the optional Network Processor (NP) Interface Module is installed in the SLM-5650B Satellite
Modem.
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to Query
Router Ethernet
Interface Traffic
IP Address and
Range
BRT= 1 byte Command or Query.
Used to set the NP card’s Bridged Point to Multipoint mode,
where:
0 = Off
1 = On
Example: BRT = 0
BRT=
BRT?
BRT*
BRT#
BRT? BRT=a
(see Description of
Arguments)
Router Working
Mode
GBM=
1 byte
Command or Query.
Used to set the NP Card’s Working Mode where:
1 = Vipersat Hub
2 = Vipersat Hub Expansion
3 = Vipersat Remote
4 = Vipersat Remote Expansion
5 = Multipoint Hub
6 = Multipoint Remote
7 = Point to Point
8 = GigaBit Bridge
Example: GBM = 7
GBM=
GBM?
GBM*
GBM#
GBM?
GBM=a
(see Description of
Arguments)
Router Ethernet
Interface
Management IP
Address and
Range
MIP= 18 bytes Command or Query.
Used to set the IP address and network prefix for the
NP Interface Management port, in the form aaa.bbb.ccc.ddd.ee,
where:
aaa.bbb.ccc.ddd = IP address
ee = network prefix (0-31)
Example: MIP = 010.006.030.001.24
MIP=
MIP?
MIP*
MIP#
MIP? MIP=aaa.bbb.ccc.ddd.ee
(see Description of
Arguments)
