B.1.1 OM-73 Mode
Modulation Type
Data Rate (kbps) Symbol Rate (ksps)
Min Max Min Max
BPSK 1/1 64 8472 64 10000
BPSK 1/2 64 15000 128 30000
BPSK 3/4
64
22500
85.333
29999.999
BPSK 7/8 64 26250 73.142 30000
QPSK 1/1
64
20000
32
10000
QPSK 1/2
64
30000
64
30000
QPSK 3/4 64 45000 42.666 30000
QPSK 7/8
64
51840
36.571
29622.857
OQPSK 1/1 64 20000 32 10000
OQPSK 1/2 64 30000 64 30000
OQPSK 3/4
64
45000
42.666
30000
OQPSK 7/8 64 51840 36.571 29622.857
B.1.2 MIL-STD-188-165A Mode
Modulation Type
R-S Code
Word
R-S Depth
Data Rate (kbps) Symbol Rate (ksps)
Min Max Min Max
BPSK 1/1 Off N/A 64 8472 64 10000
BPSK 1/2 Off N/A 64 15000 128 30000
BPSK 3/4
Off
N/A
64
22500
85.333
29999.999
BPSK 7/8 Off N/A 64 26250 73.142 30000
QPSK 1/1 Off N/A 64 20000 32 10000
QPSK 1/2 Off N/A 64 30000 64 30000
QPSK 3/4
Off
N/A
64
45000
42.666
30000
QPSK 7/8
Off
N/A
64
51840
36.571
29622.857
OQPSK 1/1 Off N/A 64 20000 32 10000
OQPSK 1/2 Off N/A 64 30000 64 30000
OQPSK 3/4
Off
N/A
64
45000
42.666
30000
OQPSK 7/8
Off
N/A
64
51840
36.571
29622.857
8-PSK 2/3 Off N/A 256 51840 128 25920
8-PSK 5/6 Off N/A 256 51840 102.4 20736
BPSK 1/2 126,112 4, 8 64 13333.333 144 29999.999
BPSK 1/2
219,201
4, 8
64
13767.123
139.462
29999.999
BPSK 1/2 225,205 4, 8 64 13666.666 140.487 29999.998
