SLM-5650B Satellite Modem
Revision 2
Appendix B B–3 MN-SLM-5650B
Modulation Type
R-S Code
Word
R-S Depth
Data Rate (kbps) Symbol Rate (ksps)
Min Max Min Max
BPSK 1/2
220,200
4, 8
64
13636.363
140.8
30000
BPSK 3/4 126,112 4, 8 64 20000 96 29999.999
BPSK 3/4 219,201 4, 8 64 20650.684 92.975 29999.998
BPSK 3/4
225,205
4, 8
64
20500
93.658
29999.999
BPSK 3/4
220,200
4, 8
64
20454.545
93.867
29999.999
BPSK 7/8 126,112 4, 8 64 23333.333 82.826 30000
BPSK 7/8 219,201 4, 8 64 24092.465 79.692 29999.999
BPSK 7/8 225,205 4, 8 64 23916.666 80.278 29999.999
BPSK 7/8
220,200
4, 8
64
23863.636
80.457
30000
QPSK 1/2 126,112 4, 8 64 26666.666 72 29999.999
QPSK 1/2 219,201 4, 8 64 27534.246 69.371 29999.999
QPSK 1/2 225,205 4, 8 64 27333.333 70.243 29999.999
QPSK 1/2
220,200
4, 8
64
27272.727
70.4
30000
QPSK 3/4
126,112
4, 8
64
40000
48
30000
QPSK 3/4 219,201 4, 8 64 41301.369 46.487 29999.999
QPSK 3/4 225,205 4, 8 64 41000 46.829 30000
QPSK 3/4 220,200 4, 8 64 40909.090 46.933 30000
QPSK 7/8
126,112
4, 8
64
46666.666
41.143
30000
QPSK 7/8 219,201 4, 8 64 48184.931 39.846 29999.999
QPSK 7/8 225,205 4, 8 64 47833.333 40.139 29999.999
QPSK 7/8 220,200 4, 8 64 47727.272 40.229 30000
OQPSK 1/2
126,112
4, 8
64
26666.666
72
29999.999
OQPSK 1/2
219,201
4, 8
64
27534.246
69.371
29999.999
OQPSK 1/2 225,205 4, 8 64 27333.333 70.243 29999.999
OQPSK 1/2 220,200 4, 8 64 27272.727 70.4 30000
OQPSK 3/4
126,112
4, 8
64
40000
48
30000
OQPSK 3/4
219,201
4, 8
64
41301.369
46.487
29999.999
OQPSK 3/4 225,205 4, 8 64 41000 46.829 30000
OQPSK 3/4 220,200 4, 8 64 40909.090 46.933 30000
OQPSK 7/8 126,112 4, 8 64 46666.666 41.143 30000
OQPSK 7/8
219,201
4, 8
64
48184.931
39.846
29999.999
OQPSK 7/8
225,205
4, 8
64
47833.333
40.139
29999.999
OQPSK 7/8 220,200 4, 8 64 47727.272 40.229 30000
8-PSK 2/3 126,112 4, 8 256 51840 144 29160
8-PSK 2/3
219,201
4, 8
256
51840
139.462
28241.194
8-PSK 2/3
225,205
4, 8
256
51840
140.487
28448.78
8-PSK 2/3 220,200 4, 8 256 51840 140.8 28512
