SLM-5650B Satellite Modem
Revision 2
10/100/1000 Base-T (GbE) Interface 12–2 MN-SLM-5650B
12.2.1 Connector Pinout
The GbE Interface is comprised of one IEEE 802.3ab 1000Base-T copper interface via a single
‘RJ-45’ type female connector (J1). The LAN interface supports 10/100/1000BASE-T operation.
Table 12-1. Connector Pinout
Pin #
Description
Direction
1
BI_DA+
bidirectional
2
BI_DA-
bidirectional
3
BI_DB+
bidirectional
4
BI_DC+
bidirectional
5
BI_DC-
bidirectional
6
BI_DB-
bidirectional
7
BI_DD+
bidirectional
8
BI_DD-
bidirectional
12.3 General Specifications
General Specifications
Data Framing
10/100/1000BASE-T Interface: RFC-894 “Ethernet”
Data Framing Format (WAN)
HDLC (Standard Single Channel)
Connector
RJ-45 female, 100
Ω
Electrical Properties
Per IEEE 802.3ab
Packet Types
Burst, distributed, or IPV4
Signal Types
Serial data
Voltage Level
Per IEEE- 802.3ab
Packet Latency
50 ms maximum
Flow Control
None
Cable Length, Maximum
100 meters CAT 5 cable, patch cords and connecting hardware, per ISO/IEC
11801:1995 and ANSI/EIA/TIA-568-A (1995)
Hot Pluggable
Cable
Yes
LEDs
Link Status, link activity
