SLM-5650B Satellite Modem
Revision 2
Front Panel Operation 5–41 MN-SLM-5650B
5.2.6 SELECT: Save/Load
Save/Load: Loc:0 Action: View
Empty (E)
Use the arrow keys to select Loc, Action, or Empty, and then press [ENT].
Loc
There are 10 locations available [0 – 9]. Use the arrow keys to select the location to
either save or load a stored configuration, and then press [ENT].
View is the default setting to select and view the location before loading or saving. Otherwise,
select Save or Load at the selected location:
• To save a configuration, go through the modem’s menus and configure all the necessary
parameters. Then, select a location, select Save, and then press [ENT].
• To load a saved configuration, select the desired configuration, select Load, and then press
[ENT].
Resetting the modem will cause all configurations to be cleared!
• If a location has no saved configuration present, the bottom line
will display “Empty” as per the example shown above.
• If a location has a configuration saved to it, the bottom line will
display the date stamp for that saved configuration in “HH:MM:SS
DD/MM/YY” format:
Save/Load: Loc:0 Action: View
16:18:00 08/07/10 (E)
If a location has a configuration saved, and the user attempts to save a new configuration to that
location, the screen will display the following message:
This configuration contains data. Would
you like to overwrite it? No (E)
The default to this question is No. To overwrite, use the arrow keys to change the answer to
Yes, and then press [ENT].
A programming sequence message will briefly display, and then the screen will display the
following message before returning back to the Save/Load menu screen:
The current configuration has been saved
to the selected location.
